Mounting and cutout
- Housing
- IP40 metal, 1U rack mounting
- Dimensions
- 441.6 x 44.45 x 290 mm (lugs excluded)
ICS5400
ICS5400 Series
3onedata ICS5400: Redundancy: Ring, MRP, STP/RSTP/MSTP, ERPS; Power: 24/48VDC (12~55VDC) or 110/220VAC (85~264VAC), dual redundant. We confirm application fit and availability at RFQ.
- Redundancy
- Ring, MRP, STP/RSTP/MSTP, ERPS
- Power
- 24/48VDC (12~55VDC) or 110/220VAC (85~264VAC), dual redundant
- Operating temperature
- -40~75C operating, -40~85C storage
- Dimensions
- 441.6 x 44.45 x 290 mm (lugs excluded)
Lead time confirmed within 1 business day
1business day first reply
Replacement and compatibility
Protocols and drivers
- Redundancy
- Ring, MRP, STP/RSTP/MSTP, ERPS
Specifications
12 fields from the manufacturer datasheet. Blanks are left blank.
| Ports Copper | 12 or 24x 10/100/1000Base-T(X) RJ45 by model |
|---|---|
| Ports Sfp | 0, 8 or 16x 100/1000Base-X Gigabit SFP by model |
| Ports 10g | 4x 1G/2.5G/10GBase-X SFP+ |
| Layer | Layer 3 managed |
| Switching | Backplane bandwidth 160G, MAC 32K, buffer 32Mbit, delay <10us |
| Routing | RIP, RIPng, OSPF, OSPFv3, ISIS, VRRP, IPv6 VRRP, BGP |
| Redundancy | Ring, MRP, STP/RSTP/MSTP, ERPS |
| Power | 24/48VDC (12~55VDC) or 110/220VAC (85~264VAC), dual redundant |
| Power Consumption | <47.3W |
| Temp | -40~75C operating, -40~85C storage |
| Housing | IP40 metal, 1U rack mounting |
| Dimensions | 441.6 x 44.45 x 290 mm (lugs excluded) |
| Model number | ICS5400 |
|---|---|
| Brand | 3onedata |
| Category | Industrial Gateways |
| Availability | Typically in stock, quantity and lead time confirmed at RFQ |
Request quotation
Send the application, quantity and target date. We will check fit and availability.
What we check
We check the ports, topology, protocol map, timing and management needs before selecting the ICS5400.
Managed features depend on the selected hardware and firmware.
A matching protocol name does not guarantee the same data map or timing.
Ports, topology, power, security and diagnostics need a full network check.
A line-by-line BOM review checks the whole list against the application before it becomes an order.
